Description
Product specifications
| Model | TE5180 |
|---|---|
| Product type | Children's wall-hung urinal |
| Material | Ceramic |
| Dimensions | 270 x 320 x 400 mm |
| Installation | Wall-hung, back-to-wall installation |
| Catalogue colours | Red,Yellow,Green,Blue |
Configuration options
| TE5180P | Flush control: No flush kit shown Drainage: Floor drainage Included / shown components: Mounting hook, Floor drainage set |
|---|---|
| TE5180P1 | Flush control: Manual delayed-action valve Water inlet: Top inlet Drainage: Floor drainage Included / shown components: Manual delayed-action flush valve, Mounting hook, Floor drainage set |
| TE5180P1S | Flush control: Wall-mounted sensor kit Water inlet: Top inlet Drainage: Floor drainage Included / shown components: Wall-mounted sensor flush kit, Mounting hook, Floor drainage set |
| TE5180P7 | Flush control: Cylindrical sensor flush valve Water inlet: Top inlet Drainage: Wall drainage shown Included / shown components: Cylindrical sensor flush valve, Mounting hook, Mounting screws, Wall drainage connector |
Catalogue source: Information and configuration options are transcribed from the supplied urinal catalogue. Final dimensions, inlet, drainage, sensor or flush-control selection and installation compatibility must be confirmed before quotation.
